Mr-Act (EX) Explosion-Proof Gas Telemetry Imaging Early Warning System

Main Technical Specifications

• Detection Range: ≥3km

• Sensitivity: 30mg/m² (SF6)

• Alarm Response Time: ≤5s

• Airborne Probe: ≤5kg (DJI M300/M350 compatible)

• Vehicle/Fixed: ≤30kg, shock resistant

• Explosion-proof: ≤150kg, Exdb II CT6 Gb

Application areas:

• Environmental Protection Department Emergency & Environmental Monitoring

• Early warning for leakage of hazardous gases and polluting gases in various industrial parks

• Petroleum and petrochemical safety monitoring, fire department emergency monitoring

• Online monitoring of traffic emission pollution gases

• Special Toxic Gas Monitoring (CWA)

Main features:

• Fast detection speed and high spectral resolution

• Strong vibration resistance and high reliability

• Visual window, friendly interface, intelligent recognition, easy to operate

• Passive, non-contact long-distance monitoring, detection distance up to 5 kilometers (actual measurement)

• It has multiple working modes such as fixed-point detection, 360° all-round detection and customized area detection.

• Military grade mercury cadmium telluride detector, thermal sensitivity ≤25mK

• Gas detection sensitivity can reach ppm level

• Can be customized to carry drones

• Explosion-proof can be customized, and the explosion-proof number is: Ex db Ⅱ C T6 Gb/Ex tb Ⅲ C T80℃ Db

• Rapid deployment and high mobility
