SDP Dry Screw Vacuum Pump Applications:
1. Petrochemical industry, used for extracting condensable gas, or toxic gas, or corrosive gas, or gas containing micro-dust.
2. In pharmaceutical industry, it is for vacuum drying of drugs, recovery of drug intermediates, recovery of gas disinfectant, and provision of clean and aseptic conditions for artificial organs.
3. Semiconductor synthesis and liquid crystal production
4. All applications for oil-free and water-free vacuum treatment field.
5. Chemical industry, used for vacuum distillation and solvent extraction and recovery, such as acetone, polyol and others.
6. Industrial exhausting; Centralized vacuum processing system
7. Mixing process of extruder and exhaust process of panel/plate processing
8. The process of debuffing mixed resin; Used in fatty acid production to eliminate water pollution and blockage in ejectors.
9. For food industry, it is used for perfume, essence concentration and etc..
Advantages and characteristics:
● No pollution due to oil-free and water-free.
● Wide range of applications, with high vacuum performance.
● Perfect vacuum treatment capacity: 100-800m3/h.
● Seal: Lip seal, mechanical seal and other forms are all available.
● Coating standard: corrosion resistant and heat resistant Harrington alloy
● Simple structure with easy maintenance, and no wearing parts and long life.
●Low power consumption, low noise, low vibration, good dynamic balance, no inertial force, high speed operation.
Technical Data:
Model No. | Suction Volume | Ultimate Pressure | Motor Power | Speed | Inlet Dia. | Outlet Dia. | Liquid Flow | Noise | Weight |
M³/h | Pa | KW | rpm | mm | mm | L/min | dB | Kg | |
SDP-200 | 150 | 6.5 | 5.5 | 2900 | 50 | 50 | 7 | 75 | 230 |
SDP-300 | 250 | 6.5 | 7.5 | 2900 | 50 | 50 | 10 | 75 | 280 |
SDP-400 | 350 | 6.5 | 11 | 2900 | 65 | 50 | 15 | 75 | 340 |
SDP-600 | 450 | 6.5 | 15 | 2900 | 80 | 50 | 15 | 75 | 580 |
SDP-800 | 650 | 6.5 | 18.5 | 2900 | 100 | 65 | 20 | 78 | 650 |
For more detailed information, please contact us.
